MacDon D1X Series - Replacing Light Bulbs

215651 128 Revision B
Table 5.2 D1X Series Wire Prefix Identification (continued)
Prefix
System
DD
Hydraulic deck shift
HA
Auger/draper adapter
;;;;;;;;;;
1

$
%
Figure 5.16: Wire Identification – Color
Color codes apply to actual wire colors on the header. For the
color code legend, refer to Table 5.3, page 128.
Wire example, XXXXXXX N18: The wire color (A) is brown and
the wire gauge (B) is 18.
Table 5.3 Wire Color Identification
ID
Color
Description
B
Black Black
N Brown Brown
DN Brown
Dark brown
LN
Brown
Light brown
U
Blue Blue
DU
Blue Dark blue
LU
Blue Light blue
G Green Green
DG Green
Dark green
LG
Light green Light green
P
Purple Purple
R
Red Red
W
White White
Y
Yellow Yellow
O Orange Orange
S
Slate
Slate (gray)
K
Pink Pink
V
Violet Violet
5.4.2 Replacing Light Bulbs
To replace the light bulbs on the header, perform the recommended replacement procedure provided here.
DANGER
To prevent bodily injury or death from the unexpected start-up of the machine, always stop the engine and remove the
key before making adjustments to the machine.
1. Shut down the engine, and remove the key from the ignition.
MAINTENANCE AND SERVICING
