MacDon D1X Series - Break-In Inspection

215651 117 Revision B
S
Knife Drive Box Lubricant (First 50 Hours
Only) - Refer to 5.6.1 Knife Drive Box,
page 146.
250 Hours
ü
Draper Seal - Refer to 5.7.2 Installing
Drapers, page 175.
S
Reel Drive U-Joint - Refer to 5.9 Reel
Drive, page 225.
S
Transport Axle Pivot Bushings - Refer to
5.10 Transport System (Option), page
239.
S
Upper Cross Auger Center Support and
U-Joint - Refer to figure5.11, page 124.
500 Hours
ü
Draper Seal - Refer to 5.7.2 Installing
Drapers, page 175.
S
Reel Drive U-Joint - Refer to 5.9 Reel
Drive, page 225.
S
Stabilizer/Slow Speed Transport Wheel
Bearings - Refer to 5.10 Transport
System (Option), page 239.
1000 Hours
▲
Knife Drive Box Lubricant - Refer to
5.6.1 Knife Drive Box, page 146.
5.3.2 Break-In Inspection
Break-in inspection involves checking belts, fluids, and performing general machine inspections for loose hardware or other
areas of concern. Break-in inspections ensure that all components can operate for an extended period without requiring
service or replacement. The break-in period is the first 50 hours of operation after the machine’s initial start up.
Inspection Interval
Item
Refer to
5 Hours
Check for loose hardware and tighten them to
required torque.
9.1 Torque Specifications, page 273
5 Hours
Check knife drive belts tension (check
periodically for first 50 hours).
• Checking and Tensioning Untimed Double-
Knife Drive Belts, page 160
• Tensioning Timed Double-Knife Drive Belts,
page 167
10 Hours
Check knife drive box mounting bolts.
Checking Knife Drive Box Mounting Bolts, page
146
50 Hours
Change knife drive box lubricant. Changing Oil in Knife Drive Box, page 157
