5.3 Maintenance Requirements
Periodic maintenance requirements are organized according to service intervals.
Regular maintenance is the best insurance against early wear and untimely breakdowns. Following the maintenance
schedule will increase your machine’s life.
When servicing the machine, refer to the specific headings in this section and use only fluids and lubricants specified in the
Recommended Fluids and Lubricants section on the inside back cover of this manual.
Log hours of operation, use the maintenance record, and keep copies of your maintenance records (refer to 5.3.1
Maintenance Schedule/Record, page 116).
If a service interval specifies more than one timeframe, e.g., 100 hours or Annually, service the machine at whichever
interval is reached first.
IMPORTANT:
Recommended intervals are for average conditions. Service the machine more often if operating under adverse conditions
(severe dust, extra heavy loads, etc.).
CAUTION
Carefully follow safety messages. Refer to 5.1 Preparing Machine for Servicing, page 113 and 1 Safety, page 1.
5.3.1 Maintenance Schedule/Record
Action
üü - Check
SS - Lubricate
▲ - Change
!
Hour Meter Reading
!
Service Date
!
Serviced By
First Use
Refer to 5.3.2 Break-In Inspection, page 117
End of Season
Refer to 5.3.4 End-of-Season Service, page 118
10 Hours or Daily
ü
Hydraulic Hoses and Lines - Refer to
5.3.5 Checking Hydraulic Hoses and
Lines, page 119.
NOTE: Keep a record of daily maintenance as evidence of a properly
maintained machine; however, daily maintenance records are not
required to meet normal warranty conditions.
ü
Knife Sections, Guards, and Hold-Downs
- Refer to 5.5 Cutterbar, page 132.
NOTE: Keep a record of daily maintenance as evidence of a properly
maintained machine; however, daily maintenance records are not
required to meet normal warranty conditions.
ü
Tire Pressure - Refer to 5.10.3 Checking
Tire Pressure, page 240.
NOTE: Keep a record of daily maintenance as evidence of a properly
maintained machine; however, daily maintenance records are not
required to meet normal warranty conditions.
S
Knife (except in sandy conditions) -
Refer to 5.5 Cutterbar, page 132.
NOTE: Keep a record of daily maintenance as evidence of a properly
maintained machine; however, daily maintenance records are not
required to meet normal warranty conditions.
25 Hours
S
Knifehead(s) - Refer to 5.5 Cutterbar,
page 132.
NOTE: Keep a record of daily maintenance as evidence of a properly
maintained machine; however, daily maintenance records are not
required to meet normal warranty conditions.
50 Hours
ü
Draper Roller Bearings - Refer to 5.7.7
Draper Roller Maintenance, page 187.
MAINTENANCE AND SERVICING
