215651 126 Revision B
Every 500 Hours
Lubricate the following components every 500 hours unless otherwise stated.
NOTE:
Use High Temperature Extreme Pressure (EP2) Performance with 1% max molybdenum disulphide (NLGI Grade 2) lithium
base unless otherwise specified.
'
&
$
%
Figure 5.13: Every 500 Hours
A - Reel – Right Side Bearing C - Wheel Bearings (Four Places)
B - Reel – Center Bearing D - Reel – Left Bearing
MAINTENANCE AND SERVICING
