215651 269 Revision B
Table 8.2 Cutting Edible Beans Troubleshooting (continued)
Problem Solution
Refer to
Vines and plants build up on endsheet
Install divider rod
3.7.11 Crop Dividers, page 70
Symptom: Plant vines pinched between top of draper and cutterbar
Cutterbar fills with debris when draper
to cutterbar gap is properly adjusted
Raise header fully at each end of field
(or as required) and shift decks back
and forth to help clean out cutterbar
—
Shifting the decks with header raised
does not clean out cutterbar debris.
Manually remove debris from
cutterbar cavity to prevent damaging
the drapers
—
Symptom: Crop accumulating at guards and not moving rearward onto drapers
Reel finger pitch not aggressive
enough
Increase finger aggressiveness (cam
position)
3.7.10 Reel Tine Pitch, page 68
Reel too high
Lower reel
3.7.8 Reel Height, page 66
Minimum reel clearance to cutterbar
setting too high
Adjust minimum reel height with
cylinders fully retracted
5.8.1 Reel-to-Cutterbar Clearance,
page 198
Reel too far forward
Reposition reel 3.7.9 Reel Fore-Aft Position, page 67
Symptom: Crop wrapping around reel
Reel too low Raise reel
3.7.8 Reel Height, page 66
Symptom: Reel shattering pods
Reel too far forward
Reposition reel 3.7.9 Reel Fore-Aft Position, page 67
Reel speed too high Reduce reel speed 3.7.4 Reel Speed, page 64
Bean pods too dry
Cut at night when heavy dew is
present and pods have softened
—
Reel finger pitch not
aggressive enough
Increase finger aggressiveness (cam
position)
3.7.10 Reel Tine Pitch, page 68
Symptom: Cutterbar guards breaking
Float insufficient (float setting
too heavy)
Increase float (adjust to lighter float
setting)
3.7.2 Header Float, page 63
Excessive number of rocks in field
Consider installing optional stub
guards
Note: Install a few guards on one
section of the cutterbar and compare
the performance of the two different
guard styles
5.5.7 Knife Guards, page 137
TROUBLESHOOTING
