215651 29 Revision B
Table 2.1 Header Specifications (continued)
Guard Angle – Cutterbar on Ground
Center-link retracted
D115X,
D120X,
D125X
7.5°
S
Center-link retracted
D130XL,
D135XL,
D140XL,
D145XL
2.5°
S
Center-link extended
D115X,
D120X,
D125X
17.0°
S
Center-link extended
D130XL,
D135XL,
D140XL,
D145XL
12.0°
S
Conveyor (Draper) and Decks
Draper width (D1X Series)
1057 mm (41.6 in.)
S
Draper width (D1XL Series)
1270 mm (50 in.)
S
Draper drive Hydraulic
S
Draper speed
225 m/min. (0–742 fpm)
S
Delivery opening width (center delivery), variable by
shifting decks
4.6 m
(15 ft.)
1540–1770 mm
(60 5/8 – 69 11/16 in.)
S
Delivery opening width (center delivery), variable by
shifting decks
6.1–13.7 m
(20–45 ft.)
1720–1950 mm
(67 1/8 – 76 11/16 in.)
S
PR15 Pick-Up Reel
Quantity of tine tubes 5, 6, or 9
—
Center tube diameter
10.7 m (35 ft.)
(single reel) only
254 mm (10 in.)
—
Center tube diameter
All reel sizes (except
10.7 m [35 ft.] single reel)
203 mm (8 in.)
—
Finger tip radius
Factory-set
800 mm (31 1/2 in.)
—
Finger tip radius Adjustment range
766–800 mm
(30 3/16 – 31 1/2 in.)
—
Effective reel diameter (via cam profile)
1650 mm (65 in.) —
Finger length
290 mm (11 in.) —
Finger spacing (staggered on alternate bats) 150 mm (6 in.)
—
Reel drive
Hydraulic
S
Reel speed (auto-adjust from cab using ground speed index)
0–85 rpm
S
