214366 129 Revision A
Every 50 Hours
1014186
A
B
C
D
E
F
A - Roll Shaft Bearings (2 Places) B - Roll Shaft Bearings (2 Places) C - Optional Gauge Roll Bearings
(2 Places Each)
D - Auger Bearing (1 Place) E - Auger Bearing (1 Place) F - Belt Tensioner Pivot (1 Place)
NOTE:
Use high temperature extreme pressure (EP2) performance with 1% max molybdenum disulphide (NLGI grade 2)
lithium base except where noted.
MAINTENANCE AND SERVICING
