Figure 5.17: Counterclockwise Disc Rotation
Direction
IMPORTANT:
The discblades have cutting edges on both sides so the
blades can be turned over and reused. The twist in each
blade determines the cutting direction. If you are unsure
which direction the spindles rotate, refer to 5.3.1
Direction of Spindle Rotation, page 137.
1003895
Figure 5.18: Clockwise Disc Rotation Direction
Inspecting Cutterblade Hardware
CAUTION
Damaged or loose discblades or blade attachment hardware can be ejected during machine operation and
may cause personal injury or machine damage.
