214366 36 Revision A
3.5.3 Opening the Cutterbar Doors: Export Header
Follow these steps to open the cutterbar doors on an export header:
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and
remove the key from the ignition before leaving the operator’s seat for any reason.
1014155
A
Figure 3.16: Curtain Latches
1. Unhook curtain latches (A).
OPERATION
