MacDon R85 - Closing the Cutterbar Doors: Export Header

214366 37 Revision A
1014164
A
B
Figure 3.17: Cutterbar Door Latch
2. Insert a screwdriver (or equivalent) through hole (A) in
door into notch in latch (B) and push latch to disengage.
3. Lift at front of door to open.
3.5.4 Closing the Cutterbar Doors: Export Header
To close the cutterbar doors on an export header follow these steps:
CAUTION
To avoid injury, keep hands and fingers away from corners of doors when closing.
OPERATION
