MacDon R85 - Page 55

214366 38 Revision A
1014156
A
Figure 3.18: Cutterbar Door Latch
1. Pull at top and move to closed position. Ensure latch (A)
has engaged the door.
1014155
A
Figure 3.19: Curtain Latches
2. Hook curtain latches (A).
OPERATION
