2 Product Overview
2.1 Definitions
The following terms and acronyms may be used in this manual.
Term
Definition
API American Petroleum Institute
ASTM American Society of Testing and Materials
Bolt
A headed and externally threaded fastener that is designed to be paired with a nut
Cab-forward Windrower operation with Operator and cab facing in direction of travel
CDM Cab display module on a self-propelled windrower
Center-link
A hydraulic cylinder link between header and machine used to change header angle
CGVW Combined gross vehicle weight
DWA Double Windrow Attachment
ECM
Engine control module
ECU
Electronic control unit
Engine-forward Windrower operation with Operator and engine facing in direction of travel
Export header
Header configuration typical outside North America
Finger tight
Finger tight is a reference position where sealing surfaces or components are
making contact with each other, and fitting has been tightened to a point where
fitting is no longer loose
FFFT
Flats from finger tight
GSS Grass Seed Special
GVW Gross vehicle weight
Hard joint
A joint made with use of a fastener where joining materials are highly
incompressible
Header
A machine that cuts and lays crop into a windrow and is attached to a self-propelled
windrower
Hex key
A tool of hexagonal cross-section used to drive bolts and screws that have a
hexagonal socket in head (internal-wrenching hexagon drive); also known as an
Allen key and various other synonyms
hp Horsepower
ISC Intermediate Speed Control
JIC
Joint Industrial Council: A standards body that developed standard sizing and shape
for original 37° flared fitting
M Series windrower
MacDon M100, M105, M150, M155, M155E4 , M200, and M205 windrowers
M1 Series windrower
MacDon M1170 and M1240 windrowers
n/a
Not applicable
