214366 22 Revision A
2.3 Specifications
NOTE:
Specifications and design are subject to change without notice or obligation to revise previously sold units.
S: standard / O: optional / O
D
: optional (dealer installed) / -: not available
4.9-Meter (16-Foot) R85
Cutterbar
Effective cutting width
4827 mm (15.83 ft.)
Number of cutting discs
10
Number of blades per disc
2
11 degree bevel up knives
S
Inline spur gear cutterbar design
S
Geartrain protection - shearable key in spindle (all discs)
S
Tall crop feed plates (stored on header)
2
Austempered cutting discs
S
Knife tip speed
82.9 mps (184 mph)
Range of cutting disc rpm
1800–2600 rpm
Knife tip speed range
59.2–85.5 mps
(131–189 mph)
Cutterbar spindle anti-wrap ring
S
Austempered rock guards
S
Hourglass converging impellers
S
Heat treated crop lifters
S
Cutting angle range 0-8° below horizontal
Cutting angle range - minimum cut height 19 mm (3/4 in.)
Adjustable gauge rollers
O
Adjustable shoes
O
Overshot Auger
Peripheral diameter
229 mm (9.0 in.)
Center tube diameter
152 mm (6.0 in.)
Rpm range
720–1040
Three HB belt drive (with spring loaded idler)
S
Universal joint in auger center
S
PRODUCT OVERVIEW
