214366 131 Revision A
Every 250 Hours
1014197
A
B
C
A - Drain and Refill Bevel Gearbox Lube
6
B - Drain and Refill Conditioner Gearbox Lube
6
C - Drain and Refill Cutterbar Lube
7
MAINTENANCE AND SERVICING
6. Refer to Changing the Bevel Gearbox Lubricant, page 158.
7. Refer to 5.2.7 Lubricating the Cutterbar, page 132.
