214366 29 Revision A
Disengage safety props as follows:
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and
remove the key from the ignition before leaving the operator’s seat for any reason.
1014507
A
Figure 3.4: Safety Prop
1. Turn lever (A) away from header to raise safety prop
until lever locks into vertical position. Repeat for
opposite cylinder.
2. Start engine, choose a level area, and lower header to
the ground.
3. Stop the engine, and remove the key.
OPERATION
