214366 61 Revision A
1014791
A
Figure 3.67: Cylinder Safety Prop
19. Disengage safety prop by turning lever (A) downward to
raise safety prop until lever locks into vertical position.
NOTE:
If safety prop will not disengage, raise header slightly.
20. Repeat for opposite side.
1014802
A
Figure 3.68: GSL
21. Start engine and press HEADER DOWN switch (A) on
GSL to fully lower header.
1015851
A
B
Figure 3.69: HPT Display
22. Press rotary scroll knob (A) on Harvest Performance
Tracker (HPT) to highlight QuickMenu options.
23. Rotate scroll knob (A) to highlight HEADER FLOAT
symbol (B), and press scroll knob to select.
OPERATION
