OPERATION93

MACKENGINEINFORMATION

Forenginestartingprocedures,referto“STARTINGTHEVEHICLE”,page126.

PrecautionsandWarnings

CAUTION

Donotpermitaheavyloadtodrive

theengineabovethegovernedspeed.

Operateinagearlowenoughtoallow

theenginetoaccelerateto(ormaintain)

governedspeedwhenapplyingthe

throttle.

WARNING

Misuseormodicationofaturbocharger

canresultinseriousinjuryandproperty

damage.Inaddition,extremecaremustbe

takentoavoidforeignmaterialinduction,

excessiveexhausttemperaturesandlackof

lubrication.
