186Mack,EmissionsSolution

InstrumentCluster

Theaftertreatmenticonsarelocatedintheinstrumentclusterperthefollowingimages.

(Example)InstrumentCluster

W3061563

1.MalfunctionIndicator

Lamp(MIL)

2.CHECKLamp

3.AftertreatmentDEF

LowLamp

4.HighExhaust

Temperature(HEST)

Lamp

5.AftertreatmentDEF

TankGauge
