Mack,EmissionsSolution185

DriverWarningsandOnBoardDiagnostics(OBD)

OnBoardDiagnostics(OBD)

BeginningwithyourADR80/03compliantVehicle,OnBoardDiagnostics(OBD)is

introduced.ThisisverysimilartotheOnBoardDiagnostics(OBD)systemthathasbeen

requiredonpassengercarsformanyyears.

OnBoardDiagnostics(OBD)isasystemthatmonitorsthefunctionsofemissionsrelated

componentsandalertsthevehicleoperatortoanydetectedneedforanemissionrelated

repair.Whenthesystemsdetectsaneededrepairtoanemissionsrelatedcomponentit

activatestheMalfunctionIndicatorLamp(MIL).

ThelistofemissionsrelatedcomponentscanbefoundintheWarrantyandMaintenance

sectionofthismanual.
