INSTRUMENTSANDCONTROLS63
CABCLIMATECONTROL
C0032677
1.BlowerControlKnob4.Fresh/RecirculationButton
2.TemperatureControlKnob5.A/CON/OFFButton
3.ModeKnob
1BlowerControlKnob—ThisknobcontrolsfanspeedfromOFFto4(highestspeed).
2TemperatureControlKnob—Controlsthetemperatureoftheairinthecabfrom
COOL(farleft)toHOT(farright).
3ModeSelectionKnob—Controlsthedirectionofairowaroundthecabasfollows:
Note:TheModeSelectionknobcanberotatedtoanyposition(seeabove).Thisallowsthe
operatortoselectthedesiredamountofblendbetweenthepositions.
C0032678
