58INSTRUMENTSANDCONTROLS

FunctionofOptionalSwitches

W3061335

OptionalSwitches

1.AccessoryBatteryPowerSwitch9.FanControlManualOverrideSwitch

2.AccessoryIgnitionPowerSwitch10.5thWheelSlideSwitch

3.AirSuspensionControlSwitch11.Inside/OutsideAirSwitch

4.AutomaticTractionControlSwitch12.LoadLightSwitch

5.BodyWarningLamp

13.MirrorDefrostSwitch

6.DaytimeRunningLightsOverride

Switch

14.Motorized-MirrorJoyStick

7.EngineBrakeSwitch15.PowerDividerLockoutSwitch

8.BlankSwitch16.PowerT ake-OffControlSwitch
