MIRRORBREAKAWAYSTRUT(IFEQUIPPED)

Themirrorbreakawaystrutsteadiesthemirror,andisdesignedto"break-away"should

themirrorhitanobject.Thebreakawaystrutneedsnomaintenance,andshouldnever

needtobereplaced.

Tore-attachthestruttothemirrorbracket:

1Pushmirrorbracketforward,asfarasitwillgo.

2Alignendofstrutwithslotinreceptacle.

3Pullbracketrearwardtosnapstrutinplace.Thestrutheadshouldbecenteredfore-aftin

thereceptacle.

C0032884

1.MirrorBracket3.PlasticStrutHead

2.Receptacle4.MirrorBreakawayStrut
