Mack CSM 2010 - Mdrive Relay Center

MAINTENANCEANDLUBRICATION213
mDRIVERelayCenter
W3061662
mDRIVEBacksidePanel
1.10ampFuse(F71A)IgnitionPowerto
GSECU
2.20ampFuse(F80)Batterypowerto
TECU
3.30ampFuse(F81A)Batterypowerto
relay73
4.10ampFuse(F79)Batterypowertogear
SelectorandGECU
5.Relay93EngineRetarderLA TCH6.Relay72GSECUIgnition
7.Relay91EngineRetarderAUTO8.Relay47mDRIVEReverseSignal
9.Relay73mDRIVEPower
10.Relay94EngineRetarderENABLE
