INSTRUMENTSANDCONTROLS65

LIGHTCONTROLPANEL

Thelightcontrolpanelislocatedonthedriversideofthedash.Thispanelcontrolsthe

interiorpanellightsandheadlights.

C0032679

1.LightControlKnob2.PanelDimmerSwitch

Withthelightcontrolknobintheleftposition,alllightsareoff.Withtheknobinthemiddle

position,theparkinglightsandinteriorpanellightswillilluminate.Withtheknobinthefar

rightposition,theheadlightswillturnon.

Toadjusttheintensityofthepanellight,movethepaneldimmerswitchbackandforth.
