188Mack,EmissionsSolution

TheAftertreatmentDEFTankLowLevelIndicatoriconilluminateswhentheuidlevelis

low.ItalsoFlasheswhenthelevelbecomescriticallylow.

W2029416

AftertreatmentDEFTankLowLevelIndicator(DEF)

MalfunctionIndicatorLamp(MIL)

•MILindicatesgovernmentRegulationOnBoardDiagnostics(OBD)faults

•Lampmayremainactiveafterrepairuntilsystemconrmsrepair

W3031200

MILLamp
