OutsideMirrorHeater

Inareasoffrequentrainandfog,itmaybebenecialtoinstallheatedmirrorswhichwill

demistcabmirrors.Heatedmirrorseliminatetheneedtopulloffthehighwayandstandon

theroadsidetocleanthemirrorsduringpoordrivingconditions.

C0032648

AirHornShield

Installationofanairhornshieldisrecommendedtopreventcontaminationoftheairhorn

bell(maintainingmaximumsoundoutput).

C0032650
