214MAINTENANCEANDLUBRICATION

ElectricalGrease

Topreventcorrosionofthelampsocketterminals,particularlywiththeclearanceand

markerlamp,applyacoatingofelectricalsealinggrease,suchasLubriplateDS-ESor

TEK-519,tothesocketandterminalassemblies.

CAUTION

DonotuseelectricalgreaseonanyV-MAC

connectors.
