148OPERATION

C0032896

T310MANDT310METRANSMISSIONRATIOS

Gear(MainBox)LORange

HIRange

Reverse

LO-LO17.3515.22

LO11.4010.00

1/5

7.451.946.54

2/6

5.331.394.67

3/7

3.831.003.37

4/8

2.780.732.44
