INSTRUMENTSANDCONTROLS55
52.RadioBox–Seeseparateowner’smanualonradioinstruction.
53.Microphone–Usedforhandfreecommunication
54.CabClimateControl–SeeinstructionsunderCabClimateControllistedin
theInstrumentandControlsSectionofthismanual.
55.DPFSmartSwitch(Cummins)–Thisisathree-positionswitchwherethe
middlepositionisneutral.
•UpperPosition–Regenerationposition
•MiddlePosition–NeutralPosition
•DownPosition–InhibitPosition
55.OptionalSwitch(mDRIVE)–Referto“FunctionofOptionalSwitches”,page58
56.PowerDividerLockoutSwitch(mDRIVE)
57.LoadLightSwitch(mDRIVE)–Referto
“FunctionofOptionalSwitches”,
page58
58.DifferentalLockoutSwitch(mDRIVE–
59.ParkingBrakeValve–Yellowdiamond-shapedknob.Pulltoapply.Pushto
release.Appliestractorparkingbrakesandtrailerbrakes,ifequipped.
60.OptionalSwitch–Referto
“FunctionofOptionalSwitches”,page58
61.TrailerAirSupplyValve–Redoctagonally-shapedknob.Pulltoapplytrailer
emergencybrakes.Pushtopressurizethetrailerairreservoir,releasingthetrailer
emergencybrakes.
Note:ThetrailerairsupplyvalveshouldNOTbeusedforparking.
62.OptionalSwitch–Referto“FunctionofOptionalSwitches”,page58
63.SuspensionHeightSwitch(mDRIVE)–Referto“FunctionofOptional
Switches”,page58
64.OptionalSwitch–Referto
“FunctionofOptionalSwitches”,page58
65.OptionalSwitch–Referto“FunctionofOptionalSwitches”,page58
66.OptionalSwitch(Cummins)–Referto“FunctionofOptionalSwitches”,
page58
66.DrivingLightSwitch(mDRIVE)–Turnsonthedrivinglights.
67.SpeedControlSwitch––ThisisaV-MAC®switch;refertotheV-MAC®
IVVehicleManagementandControlwithCo-Pilot®DisplayOperator’sGuidefor
moreinformation
68.WiperSwitch–manuallyturnsonwipers.
69.OptionalSwitch–Referto“FunctionofOptionalSwitches”,page58
