INSTRUMENTSANDCONTROLS71

UP&DOWNBUTTONS

TheUp&Downbuttonsattheendofthestalkswitchallowtheusertohighlightthevarious

availablemenuitems.Sometimes,thesebuttonsareusedtoenterinformationintothe

displays.

•UpButton—Onceatthetopofthemenuitemsthatcanbeselected,pressingtheUp

buttonwilltakethedisplaytothelastiteminthemenu.

FormoreinformationonCo-Pilot®display,pleaserefertotheV-MAC®IVV ehicle

ManagementandControlwithCo-Pilot®DisplayOperator’sGuide.
