Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 134
Table 5-59: Voltage/Frequency (V/f) Pattern Options (575 V)
* Default for O02-09 = 1 (US) and not Std Hoist
*1 Default for O02-09 = 1 (US) and Std Hoist
*2 Default for O02-09 = 2 (Euro) and not Std Hoist
*3 Default for O02-09 = 2 (Euro) and Std Hoist
E01-04 E01-05 E01-06 E01-07 E01-08 E01-09 E01-10 E01-11 E01-12 E01-13
E01-03 Hz VAC Hz Hz VAC Hz VAC Hz VAC VAC
0* 60.0 575.0 60.0 3.0 37.5 1.3 20.3 0.0 0.0 0.0
1 60.0 575.0 60.0 3.0 40.3 1.3 23.0 0.0 0.0 0.0
2 60.0 575.0 60.0 3.0 43.3 1.3 26.0 0.0 0.0 0.0
3 60.0 575.0 60.0 3.0 46.0 1.3 28.8 0.0 0.0 0.0
4*
1
60.0 575.0 60.0 3.0 49.0 1.3 31.8 0.0 0.0 0.0
5 60.0 575.0 60.0 3.0 51.8 1.3 34.5 0.0 0.0 0.0
6 60.0 575.0 60.0 3.0 54.8 1.3 37.5 0.0 0.0 0.0
7 60.0 575.0 60.0 3.0 57.5 1.3 40.3 0.0 0.0 0.0
8 60.0 575.0 60.0 3.0 60.5 1.3 43.3 0.0 0.0 0.0
9*
2
50.0 500.0 50.0 2.5 32.6 1.1 17.7 0.0 0.0 0.0
A 50.0 500.0 50.0 2.5 37.7 1.1 22.6 0.0 0.0 0.0
B*
3
50.0 500.0 50.0 2.5 42.6 1.1 27.7 0.0 0.0 0.0
C 50.0 500.0 50.0 2.5 47.7 1.1 32.6 0.0 0.0 0.0
D 75.00 500.0 50.0 2.5 42.6 1.1 27.7 0.0 0.0 0.0
E 90.00 575.0 60.0 3.0 49.0 1.3 31.8 0.0 0.0 0.0
US (V/f)
F & FF
60.0 575.0 60.0 3.0 49.0 1.3 31.8 0.0 0.0 0.0
Euro (V/f)
F & FF
50.0 500.0 50.0 2.5 42.5 1.3 27.5 0.0 0.0 0.0
US (OLV)
F & FF
60.0 575.0 60.0 3.0 34.5 0.5 7.3 0.0 0.0 0.0
Euro (OLV)
F & FF
50.00 500.0 50.0 2.5 30.0 0.5 6.3 0.0 0.0 0.0
