IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 133
Table 5-58: Voltage/Frequency (V/f) Pattern Options (460 V)
* Default for O02-09 = 1 (US) and not Std Hoist
*1 Default for O02-09 = 1 (US) and Std Hoist
*2 Default for O02-09 = 2 (Euro) and not Std Hoist
*3 Default for O02-09 = 2 (Euro) and Std Hoist
E01-04 E01-05 E01-06 E01-07 E01-08 E01-09 E01-10 E01-11 E01-12 E01-13
E01-03 Hz VAC Hz Hz VAC Hz VAC Hz VAC VAC
0* 60.0 460.0 60.0 3.0 29.9 1.3 16.2 0.0 0.0 0.0
1 60.0 460.0 60.0 3.0 32.2 1.3 18.4 0.0 0.0 0.0
2 60.0 460.0 60.0 3.0 34.6 1.3 20.8 0.0 0.0 0.0
3 60.0 460.0 60.0 3.0 36.8 1.3 23.0 0.0 0.0 0.0
4*
1
60.0 460.0 60.0 3.0 39.1 1.3 25.4 0.0 0.0 0.0
5 60.0 460.0 60.0 3.0 41.4 1.3 27.6 0.0 0.0 0.0
6 60.0 460.0 60.0 3.0 43.8 1.3 30.0 0.0 0.0 0.0
7 60.0 460.0 60.0 3.0 46.0 1.3 32.2 0.0 0.0 0.0
8 60.0 460.0 60.0 3.0 48.4 1.3 34.6 0.0 0.0 0.0
9*
2
50.0 400.0 50.0 2.5 26.1 1.1 14.1 0.0 0.0 0.0
A 50.0 400.0 50.0 2.5 30.1 1.1 18.1 0.0 0.0 0.0
B*
3
50.0 400.0 50.0 2.5 34.1 1.1 22.1 0.0 0.0 0.0
C 50.0 400.0 50.0 2.5 38.1 1.1 26.1 0.0 0.0 0.0
D 75.00 400.0 50.0 2.5 34.1 1.1 22.1 0.0 0.0 0.0
E 90.00 460.0 60.0 3.0 39.2 1.3 25.4 0.0 0.0 0.0
US (V/f)
F & FF
60.0 460.0 60.0 3.0 39.1 1.3 25.3 0.0 0.0 0.0
Euro (V/f)
F & FF
50.0 400.0 50.0 2.5 34.0 1.3 22.0 0.0 0.0 0.0
US (OLV)
F & FF
60.0 460.0 60.0 3.0 27.6 0.5 5.8 0.0 0.0 0.0
Euro (OLV)
F & FF
50.00 400.0 50.0 2.5 24.0 0.5 5.0 0.0 0.0 0.0
