•G+ & VG+ Series 4 Technical Manual
November 2020
Page 132
Table 5-57: Voltage/Frequency (V/f) Pattern Options (230 V)
* Default for O02-09 = 1 (US) and not Std Hoist
*1 Default for O02-09 = 1 (US) and Std Hoist
*2 Default for O02-09 = 2 (Euro) and not Std Hoist
*3 Default for O02-09 = 2 (Euro) and Std Hoist
E01-04 E01-05 E01-06 E01-07 E01-08 E01-09 E01-10 E01-11 E01-12 E01-13
E01-03 Hz VAC Hz Hz VAC Hz VAC Hz VAC VAC
0* 60.0 230.0 60.0 3.0 15.0 1.3 8.1 0.0 0.0 0.0
1 60.0 230.0 60.0 3.0 16.1 1.3 9.2 0.0 0.0 0.0
2 60.0 230.0 60.0 3.0 17.3 1.3 10.4 0.0 0.0 0.0
3 60.0 230.0 60.0 3.0 18.4 1.3 11.5 0.0 0.0 0.0
4*
1
60.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
5 60.0 230.0 60.0 3.0 20.7 1.3 13.8 0.0 0.0 0.0
6 60.0 230.0 60.0 3.0 21.9 1.3 15.0 0.0 0.0 0.0
7 60.0 230.0 60.0 3.0 23.0 1.3 16.1 0.0 0.0 0.0
8 60.0 230.0 60.0 3.0 24.2 1.3 17.3 0.0 0.0 0.0
9*
2
50.0 200.0 50.0 25 13.0 1.1 7.0 0.0 0.0 0.0
A 50.0 200.0 50.0 25 15.0 1.1 9.0 0.0 0.0 0.0
B*
3
50.0 200.0 50.0 25 17.0 1.1 11.0 0.0 0.0 0.0
C 50.0 200.0 50.0 25 19.0 1.1 13.0 0.0 0.0 0.0
D 75.00 200.0 50.0 25 17.0 1.1 11.0 0.0 0.0 0.0
E 90.00 230.0 60.0 30 19.6 1.3 12.7 0.0 0.0 0.0
US (V/f)
F & FF
60.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
Euro (V/f)
F & FF
50.0 200.0 50.0 2.5 17.0 1.3 11.0 0.0 0.0 0.0
US (OLV)
F & FF
60.0 230.0 60.0 3.0 13.8 0.5 2.9 0.0 0.0 0.0
Euro (OLV)
F & FF
50.00 200.0 50.0 2.5 12.0 0.5 2.5 0.0 0.0 0.0
