Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 131
* Initial value determined by X-Press Programming (Table 4-6 on page 59, Table 4-7 on page 60 or Table 4-8 on page 61).
E01-05 Max Voltage Maximum Voltage 230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
Determined
by O02-04
E01-06 Base Frequency Motor Base Frequency 0.0–150.0 Hz 60.0
E01-07 Mid Frequency A Midpoint Output Frequency A 0.0–150.0 Hz Determined
by E01-03
E01-08 Mid Voltage A Midpoint Output Voltage A 230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
Determined
by E01-03
E01-09 Min Frequency Minimum Output Frequency 0.0–150.0 Hz Determined
by E01-03
E01-10 Min Voltage Minimum Output Voltage 230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
Determined
by E01-03
E01-11 Mid Frequency B Midpoint Output Frequency B 0.0–150.0 Hz 0.0
E01-12 Mid Voltage B Midpoint Output Voltage B 230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
0.0
E01-13 Base Voltage Motor Base Voltage 230 V: 0.0–255.0
460 V: 0.0–510.0
575 V: 0.0–733.1
0.0
Parameter Display Function Range Default
