IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 160
Table 5-82: Option Selections for H03-02, H03-06, and H03-10 (V/f)
Display Function
0 Analog Freq Ref1 100% = Max output frequency (E01-04) Same value can be set using H03-02 and H03-10.
10V = E01-04 (Maximum output frequency)
1 Frequency Gain Analog frequency bias will be multiplied with the analog frequency reference gain.
2 Analog Freq Ref2 Max. output frequency
10V = E01-04 (Maximum output frequency)
3 Analog Freq Ref3 Max. output frequency
10V = E01-04 (Maximum output frequency)
4 Voltage Bias Output Voltage Bias. This bias boosts the output voltage of the V/f curve as a percentage of the
maximum output voltage (E01-05). Only available in V/f mode.
10V = E01-05 (Motor rated Voltage)
5 Acc/Dec T Reduct 10V = 100%
6 DC Inj Braking DC Injection Braking Current
10V = 100% VFD rated current
4 to 20 mA = 0 to 100% VFD rated current
7 OT / UT Det Lvl Motor rated torque (vector control); VFD rated current (V/f control)
8 Stall Prev Level Enables analog stall prevention input
9 Ref Lower Limit Max. output frequency
10V = E01-04 (Maximum output frequency)
D Freq Ref Bias 2 The input value of an analog input set to this function will be added to the frequency reference.
This function can be used with any frequency reference source.
E MotorTemperature PTC thermistor input. Set DIP switch S4 to “PTC.”
16 Load Cell Used for Weight Measurement
1F Not Used -
