Table 5-81: Option Selections for H03-02, H03-06, and H03-10 (Flux Vector)
H03-16 TerminalA1Offset Adds an offset when the analog signal to
terminal A1 is 0V
-500–500 0
H03-17 TerminalA2Offset Adds an offset when the analog signal to
terminal A2 is 0V
-500–500 0
H03-18 TerminalA3Offset Adds an offset when the analog signal to
terminal A3 is 0V
-500–500 0
Display Function
0 Analog Freq Ref1 Analog Frequency reference 1
10V = E01-04 (Maximum output frequency)
1 Frequency Gain Analog frequency reference will be multiplied with the analog frequency reference gain.
2 Analog Freq Ref2 Analog Frequency reference 2
10V = E01-04 (Maximum output frequency)
3 Analog Freq Ref3 Analog Frequency reference 3
10V = E01-04 (Maximum output frequency)
5 Acc/Dec T Reduct 10V = 100%
7 OT / UT Det Lvl Motor rated torque (vector control); VFD rated current (V/f control)
9 Ref Lower Limit Max. output frequency
10V = E01-04 (Maximum output frequency)
D Freq Ref Bias 2 The input value of an analog input set to this function will be added to the frequency reference.
This function can be used with any frequency reference source.
E MotorTemperature PTC thermistor input. Set DIP switch S4 to “PTC.”
10 FWD Torque Limit Torque limit when motoring in the forward direction.
11 REV Torque Limit Torque limit when motoring in the reverse direction.
12 Regen Torque Limit Torque limit during regen.
13 Torque Reference Torque reference when in Torque Control mode; Torque limit when in Speed Control mode.
14 Torque Comp Torque compensation when using torque control.
15 Torque Limit Torque limit when motoring.
16 Load Cell Used for Weight Measurement
1F Not Used -
Parameter Display Function Range Default
