Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 221
oFC02
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option Fault (CN5-C). Two of the
same option cards are connected
simultaneously.
• AI-A3: AI-A3 option
connected to CN5-B
port while another
input option was
connected to CN5-A
port.
• DI-A3: DI-A3 option
connected to CN5-B
port while another
input option was
connected to CN5-A
port.
• AO-A3/DO-A3:
Duplicate type of
option card is
connected to VFD
ports CN5-A, CN5-B,
and CN5-C.
• AI-A3: Only one of the options,
AI-A3, DI-A3, or SI-xx can be
connected to the VFD at the
same time.
• DI-A3: Only one of the options,
AI-A3, DI-A3, or SI-xx can be
connected to the VFD at the
same time.
• AO-A3/DO-A3: Use only
compatible options.
oFC03
to
oFC11
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option Card Fault at Option Port
CN5-C.
• Option card or
hardware is damaged.
• Cycle power to the VFD.
• If the problem continues,
replace the control board or the
entire VFD. Contact Magnetek
for instructions on replacing the
control board.
oFC12
to
oFC17
A1-A3
AO-A3
DI-A3
DO-A3
S4I
S4IO
Option Card Fault at Option Port
CN5-C.
• Option card or
hardware is damaged.
• Cycle power to the VFD.
• If the problem continues,
replace the control board or the
entire VFD. Contact Magnetek
for instructions on replacing the
control board.
oPE05
A1-A3
DI-A3
S4I
S4IO
Run command/frequency
reference source selection error.
• Frequency reference
is assigned to an
option (B03-01 = 3),
but an option is not
connected.
• Reconnect the option to the
VFD.
oPE06
- Control Method Selection Error • A control mode has
been selected that
requires a PG option
card to be installed,
but no PG encoder is
installed (A01-02 = 1
or 3).
• Connect to a PG option card.
• Correct the value set to A01-02.
oPE07
A1-A3 Multi-function Analog Input
Selection Error.
• At least two analog
input terminals are set
to the same function.
• Analog input terminal
and pulse train input
are set to the same
function.
• Adjust H03-02, H03-06, and
H03-10 settings so functions no
longer conflict.
Error Card
Fault or Indicator Name/
Description
Cause Possible Solution
