IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 231
C08-02 IFB OK Time 1.00 0.00–2.55 sec Page 104
C08-03 Min Brk Rel Trq 10 0–300 % Page 104
C08-04 Rollback Timer 0.30 0.00–2.55 sec Page 104
C08-05 Rollback Count 800 0–15000 pulses Page 104
C08-06 BE3/Alt Torq Tim 0.30 0.00–2.55 sec Page 104
C08-07 BE3 Detect Count 10 0–15000 pulses Page 104
C08-08 Alt Rev Trq Lim 25 0–300 % Page 104
C08-09 Zero Speed Level 1.0 0.0–10.0 Hz Page 104
C08-10 Load Float Time 10* 0–65535 sec Page 104
C08-11 Brake Set Delay 0.7 0.0–25.5 sec Page 104
C08-12 BE6 Detect Time 5.0 0.0–25.5 sec Page 104
C08-13 BE6 Max Count 250 0–15000 pulses Page 104
C08-14 Brake Hold Speed 0.0 0.0–25.5 % Page 104
C08-15 Load Float Ext T 10 0–65535 sec Page 104
C08-16 Init FWD Brk Trq 100 10–300 % Page 104
C08-18 BE6 Up Speed Lim 6.0 0.0–150.0 Hz Page 104
C08-19 Brk Slip Reset 0 0, 1 - Page 104
C08-20 BE6 Check Torque 1.0 0.5–20.0 % Page 104
C08-21 Add Mag I Time 0.0 0.0–3.0 sec Page 104
C08-22 Brk Slip Detect 0 0, 1 - Page 104
C08-23 Brk Slip Det Spd 1.0 0–10.0 Hz Page 104
C08-24 Brake Test Torq
1.25* (E02-
11*5252)/
F01-01
0–65535 flb Page 104
C08-25 Brake Test Speed 6 0–10 Hz Page 104
C08-33 Dual Brake Test 0 0, 1 - Page 105
C08-34 DIR Flt Trq Lvl 20 0–100% % Page 105
C09-01 Digital In Sel 0 0–2, 5 - Page 108
C09-02 DIO Terminal 1 0 0–FF - Page 108
C09-03 DIO Terminal 2 0F 0–FF - Page 108
C09-04 DIO Terminal 3 0F 0–FF - Page 108
C09-05 DIOTerminal 4 0F 0–FF - Page 108
C09-06 DIOTerminal 5 0F 0–FF - Page 108
C09-07 DIOTerminal 6 0F 0–FF - Page 108
C09-08 DIOTerminal 7 0F 0–FF - Page 108
C09-09 DIOTerminal 8 0F 0–FF - Page 108
C09-10 DIOTerminal 9 0F 0–FF - Page 108
C09-11 DIOTerminal 10 0F 0–FF - Page 108
C09-12 DIOTerminal 11 0F 0–FF - Page 108
C09-13 DIOTerminal 12 0F 0–FF - Page 108
C09-14 DIOTerminal 13 0F 0–FF - Page 108
C09-15 DIOTerminal 14 0F 0–FF - Page 108
Parameter Parameter Name Default Range Units Reference
