IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 27
Table 2-1: IP00/Open Chassis Dimensions – 230 V Class
* Total Loss is specified for continuous operation.
Model
Number
(-G+/VG+S4)
Figure
Dimensions - inches (mm)
Weight
lbs (kg)
Total
Loss
(W)*
WHDW1H1d
2003
2-5
5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) 9.76 (248) M5 7.3 (3.3) 59
2005 5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) 9.76 (248) M5 7.3 (3.3) 72
2007 5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) 9.76 (248) M5 7.5 (3.4) 84
2008 5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) 9.76 (248) M5 7.5 (3.4) 95
2011 5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) 9.76 (248) M5 7.5 (3.4) 122
2014 5.51 (140) 10.24 (260) 6.46 (164) 4.80 (122) 9.76 (248) M5 8.2 (3.7) 137
2017 5.51 (140) 10.24 (260) 6.46 (164) 4.80 (122) 9.76 (248) M5 8.2 (3.7) 168
2025 5.51 (140) 10.24 (260) 6.57 (167) 4.80 (122) 9.76 (248) M5 9.3 (4.2) 287
2033 5.51 (140) 10.24 (260) 6.57 (167) 4.80 (122) 9.76 (248) M5 9.3 (4.2) 319
2047 7.09 (180) 11.81 (300) 7.36 (187) 6.30 (160) 11.18 (284) M5 13.0 (5.9) 410
2060 8.66 (220) 13.78 (350) 7.76 (197) 7.56 (192) 13.19 (335) M6 20.1 (9.1) 558
2075 8.66 (220) 13.78 (350) 7.76 (197) 7.56 (192) 13.19 (335) M6 22.0 (10.0) 681
2085
2-6
10.00 (254) 15.75 (400) 10.16 (258) 7.68 (195) 15.16 (385) M6 46.2 (21.0) 721
2115 10.98 (279) 17.72 (450) 10.16 (258) 8.66 (220) 17.13 (435) M6 55.0 (24.9) 912
2145 12.95 (329) 21.65 (550) 11.14 (283) 10.24 (260) 21.06 (535) M6 81.4 (36.9) 1122
2180 12.95 (329) 21.65 (550) 11.14 (283) 10.24 (260) 21.06 (535) M6 83.6 (37.9) 1354
2215 17.72 (450) 27.76 (705) 12.99 (330) 12.80 (325) 26.77 (680) M10 167.6 (76.0) 1980
2283 17.72 (450) 27.76 (705) 12.99 (330) 12.80 (325) 26.77 (680) M10 176.4 (80.0) 2524
2346 19.69 (500) 31.50 (800) 13.78 (350) 14.57 (370) 30.43 (773) M12 216.1 (98.0) 3347
2415 19.69 (500) 31.50 (800) 13.78 (350) 14.57 (370) 30.43 (773) M12 218.3 (99.0) 3626
