Magnetek IMPULSE G+ 4 Series User Manual

IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 28
Table 2-2: IP00/Open Chassis Dimensions – 460 V Class
* Total Loss is specified for continuous operation.
Model
Number
(-G+/VG+S4)
Figure
Dimensions - inches (mm)
Weight
(lbs)
Total
Loss
(W)*
WHDW1W3H1d
4001
2-5
5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) - 9.76 (248) M5 7.5 (3.4) 61
4003 5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) - 9.76 (248) M5 7.5 (3.4) 70
4004 5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) - 9.76 (248) M5 7.5 (3.4) 87
4005 5.51 (140) 10.24 (260) 6.46 (164) 4.80 (122) - 9.76 (248) M5 7.9 (3.6) 101
4007 5.51 (140) 10.24 (260) 6.46 (164) 4.80 (122) - 9.76 (248) M5 8.2 (3.7) 108
4009 5.51 (140) 10.24 (260) 6.46 (164) 4.80 (122) - 9.76 (248) M5 8.2 (3.7) 130
4014 5.51 (140) 10.24 (260) 6.57 (167) 4.80 (122) - 9.76 (248) M5 9.0 (4.1) 221
4018 5.51 (140) 10.24 (260) 6.57 (167) 4.80 (122) - 9.76 (248) M5 9.0 (4.1) 247
4024 7.09 (180) 11.81 (300) 6.57 (167) 6.30 (160) - 11.18 (284) M5 12.6 (5.7) 323
4031 7.09 (180) 11.81 (300) 7.36 (187) 6.30 (160) - 11.18 (284) M5 13.2 (6.0) 403
4039 8.66 (220) 13.78 (350) 7.76 (197) 7.56 (192) - 13.19 (335) M6 19.2 (8.7) 509
4045
2-6
10.00 (254) 15.75 (400) 10.16 (258) 7.68 (195) - 15.16 (385) M6 50.7 (23.0) 518
4060 10.98 (279) 17.72 (450) 10.16 (258) 8.66 (220) - 17.13 (435) M6 59.5 (27.0) 701
4075 12.95 (329) 20.08 (510) 10.16 (258) 10.24 (260) - 19.49 (495) M6 79.2 (35.9) 817
4091 12.95 (329) 20.08 (510) 10.16 (258) 10.24 (260) - 19.49 (495) M6 79.2 (35.9) 1022
4112 12.95 (329) 21.65 (550) 11.14 (283) 10.24 (260) - 21.06 (535) M6 90.2 (40.9) 1325
4150 12.95 (329) 21.65 (550) 11.14 (283) 10.24 (260) - 21.06 (535) M6 92.4 (41.9) 1920
4180 17.72 (450) 27.76 (705) 12.99 (330) 12.80 (325) - 26.77 (680) M10 174.2 (79.0) 2313
4216 19.69 (500) 31.50 (800) 13.78 (350) 14.57 (370) - 30.43 (773) M12 211.6 (96.0) 3075
4260 19.69 (500) 31.50 (800) 13.78 (350) 14.57 (370) - 30.43 (773) M12 224.9 (102.0) 3178
4304 19.69 (500) 31.50 (800) 13.78 (350) 14.57 (370) - 30.43 (773) M12 235.9 (107.0) 4060
4370 2-7 19.69 (500) 37.40 (950) 14.57 (370) 14.57 (370) - 36.34 (923) M12 275.6 (125.0) 4742
4450
2-8
26.38 (670) 44.88 (1140) 14.57 (370) 17.32 (440) 8.66 (220) 43.70 (1110) M12 476.2 (216.0) 5358
4605 26.38 (670) 44.88 (1140) 14.57 (370) 17.32 (440) 8.66 (220) 43.70 (1110) M12 487.2 (221.0) 5875
4810
2-9
49.21 (1250) 54.33 (1380) 14.57 (370) 43.70 (1110) 13.00 (330) 52.95 (1345) M12
1201.5
(545.0)
9367
41090 49.21 (1250) 54.33 (1380) 14.57 (370) 43.70 (1110) 13.00 (330) 52.95 (1345) M12
1223.6
(555.0)
10781
