IMPULSE
®
•G+ & VG+ Series 4 Technical Manual
November 2020
Page 29
Table 2-3: IP00/Open Chassis Dimensions – 575 V Class
* Total Loss is specified for continuous operation.
Model
Number
(-G+/VG+S4)
Figure
Dimensions - inches (mm)
Weight
(lbs)
Total
Loss
(W)*
WHDW1H1d
5001
2-5
5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) 9.76 (248) M5 7.5 (3.4) 48.7
5003 5.51 (140) 10.24 (260) 5.79 (147) 4.80 (122) 9.76 (248) M5 7.5 (3.4) 81.9
5004 5.51 (140) 10.24 (260) 6.46 (164) 4.80 (122) 9.76 (248) M5 8.2 (3.7) 80.0
5006 5.51 (140) 10.24 (260) 6.46 (164) 4.80 (122) 9.76 (248) M5 8.2 (3.7) 115.1
5009 5.51 (140) 10.24 (260) 6.57 (167) 4.80 (122) 9.76 (248) M5 9.0 (4.1) 160.3
5012 7.09 (180) 11.81 (300) 7.36 (187) 6.30 (160) 11.18 (284) M5 13.2 (6.0) 212.2
5017 7.09 (180) 11.81 (300) 7.36 (187) 6.30 (160) 11.18 (284) M5 13.2 (6.0) 284.8
5022 8.66 (220) 13.78 (350) 7.76 (197) 7.56 (192) 13.19 (335) M6 19.2 (8.7) 381.1
5027 8.66 (220) 13.78 (350) 7.76 (197) 7.56 (192) 13.19 (335) M6 19.2 (8.7) 465.1
5032
2-6
10.98 (279) 17.72 (450) 10.16 (258) 8.66 (220) 17.13 (435) M6 59.5 (27.0) 533.5
5041 10.98 (279) 17.72 (450) 10.16 (258) 8.66 (220) 17.13 (435) M6 59.5 (27.0) 688.5
5052 12.95 (329) 21.65 (550) 11.14 (283) 10.24 (260) 21.06 (535) M6 99.2 (45.0) 1606.5
5062 12.95 (329) 21.65 (550) 11.14 (283) 10.24 (260) 21.06 (535) M6 99.2 (45.0) 1836.5
5077 12.95 (329) 21.65 (550) 11.14 (283) 10.24 (260) 21.06 (535) M6 99.2 (45.0) 1619.0
5099 17.72 (450) 27.76 (705) 12.99 (330) 12.80 (325) 26.77 (680) M10 174.2 (79.0) 1750
5130 17.72 (450) 27.76 (705) 12.99 (330) 12.80 (325) 26.77 (680) M10 174.2 (79.0) 2146
5172 19.69 (500) 31.50 (800) 13.78 (350) 14.57 (370) 30.43 (773) M12 235.9 (107.0) 2762
5200 19.69 (500) 31.50 (800) 13.78 (350) 14.57 (370) 30.43 (773) M12 235.9 (107.0) 3422
