Table 4-5: X-Press Programming I/O Quick Reference
A01-04 =0123456
Terminal S1 FWD FWD FWD FWD FWD FWD FWD
Terminal S2 REV REV REV REV REV REV REV
Terminal S3 Step 2Step 2Step 2Accel Hold - -
Terminal S4 - Step 3 Step 3 - Accel - -
Terminal S5--Step 4----
Terminal S6--Step 5----
Terminal S7-------
Terminal S8-------
Terminal A1-----FREFFREF
Terminal M0/M1 Brake Brake Brake Brake Brake Brake Brake
Terminal M2/M3 Brake (NLB Hoist only), otherwise not used
Terminal M5/M6 Fault Annunciate (NLB Hoist only), otherwise not used
WARNING
When changing A01-03 or A01-04, MFDI, MFDO, and speed reference parameters will be overwritten
by X-Press Programming™ (Table 4-6 on page 59, Table 4-7 on page 60, or Table 4-8 on page 61).
All parameter settings must be verified for proper operation.
