Maytag MLE22PD - SPECIFICATIONS

2-6
SPECIFICATIONS
MY180031 Rev 4/18
SPECIFICATIONS
COMBINATION STACK
WASHER / DRYER –
50Hz MODELS
MODEL – COIN READY/
CARD READY & NON-VEND
MLE22PDAGW/
MLE22PNAGW
MLG22PDAGW/
MLG22PNAGW
Int’l Int’l
Fuel Type Electric Gas
WASHER SPECIFICATIONS
CAPACITY
Cylinder Volume — cu. ft. (liters) 3.10 (88) 3.10 (88)
Cylinder Diameter — in. (mm) 21.60 (547) 21.60 (547)
Cylinder Depth — in. (mm) 13.40 (340) 13.40 (340)
WATER INLET HOSE / DRAIN HOSE
Operating Pressure – psi (bar) 20 – 100 (1 – 8) 20 – 100 (1 – 8)
Inlet Hose Length — ft. (m) 4 (1.22) 4 (1.22)
Drain Hose Length — ft. (m) 6 (1.83) 6 (1.83)
APPROXIMATE WATER USAGE
Average Total Water Usage Per Cycle — gallons (liters)* 10.71 (40.50) 10.71 (40.50)
Average Hot Water Usage, Warm Water Cycle — gallons (liters) .71 (2.69) .71 (2.69)
Average Hot Water Usage, Hot Water Cycle — gallons (liters) 2.71 (10.26) 2.71 (10.26)
ELECTRICAL REQUIREMENTS+
Voltage N/A N/A
Electrical Requirements / Frequency N/A N/A
Breaker / Fuse – amps N/A N/A
DIMENSIONS – DOOR OPENING – IN. (MM) 14.25 (362) 14.25 (362)
EXTRACT SPEED — MAX G-FORCE / MAX RPM 300 / 1,000 300 / 1,000
MOTOR SIZE — HP (KW) .09 (.07) .09 (.07)
DRYER SPECIFICATIONS
CAPACITY
Cylinder Volume — cu. ft. (liters) 6.70 (190) 6.70 (190)
Cylinder Diameter – in. (mm) 26.3 (666.8) 26.3 (666.8)
Cylinder Depth – in. (mm) 20.4 (518.3) 20.4 (518.3)
ELECTRICAL REQUIREMENTS+
Voltage 220 – 240V 220 – 240V
Electrical Requirements / Frequency 50Hz 50Hz
Breaker / Fuse – amps 30 10
DIMENSIONS – DOOR OPENING – IN. (MM) 18.25 (464) 18.25 (464)
DRYER EXHAUST DUCT DIAMETER – IN. (MM)** 4 (100) 4 (100)
AIRFLOW (CFM) 215 (6.10) 230 (6.5)
ELECTRIC HEATING ELEMENT (WATTS) 4,600
N/A
GAS RATING — BTU/HR. (KCAL/HR.) N/A 20,000 (5,040)
GAS INLET SIZE
N/A 3/8 NPT
MOTOR SIZE – HP (KW) .33 (.25) .33 (.25)
MACHINE SPECIFICATIONS
DIMENSIONS
Width — in. (mm) 27 (686) 27 (686)
Depth — in. (mm) 29.50 (751) 29.50 (751)
Height — in. (mm) 74 (1,880) 74 (1,880)
CRATED DIMENSIONS
Crated Width — in. (mm) 29.25 (743) 29.25 (743)
Crated Depth — in. (mm) 34 (864) 34 (864)
Crated Height — in. (mm) 75.75 (1,924) 75.75 (1,924)
APPROXIMATE WEIGHT
Uncrated — lbs. (kg) 372 (169) 378 (171)
Crated — lbs. (kg) 383 (173) 389 (176)
Dimensions are for planning purposes only. See specific instructions for proper installation. Because of continuous product
improvement, Maytag reserves the right to change specifications without notice.
*Based on 2018 United States DOE J2 Testing with factory preset cycles.
**Use 4” (100mm) diameter rigid aluminum or galvanized steel duct. Never use plastic, non-metal, or combustible duct.
+It is recommended that a separate circuit serving only this washer / dryer be provided.
®/TM
© 2018 Maytag. All rights reserved.
SIDE VIEW
BACK VIEW
See maytagcommerciallaundry.com
for complete warranty details.
See Installation Guide
for complete dimension details.
