4-11
1. Remove the control panel bracket
(See page 4-8).
2. Remove two 1/4” hex head screws from
each bracket on the back of the stack.
3. Lift each bracket out of a slot in the dryer.
4. With two people, lift the dryer off the top of
the washer and set it on a covered sturdy
surface.
5. The washer has a plastic strip on the top
edge of each side panel with locator pegs
that fit into the corresponding holes of the
dryer base.
6. To remove the locator strips, remove two
1/4” hex head screws from each strip.
DRYER REMOVE FROM STACK
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
Excessive Weight Hazard
Use two or more people to move and
install stacked washer/dryer.
Failure to do so can result in back or
other injury.
Two Brackets
Bracket
Slot
Locator Peg
Two 1/4”
Screws
Locator Peg
To Next Page
