4-13
1. Remove dryer door (See page 4-12).
2. Remove the Phillips head screw securing
door strike. This is a large pan head screw.
3. Rotate the top of the strike away from the
dryer and slide the tab out of the slot in the
front panel.
4. Turn strike 180° and install it on the
opposite side of the door opening.
5. Remove the hinge screw-hole cover by
gently prying two plastic pins out of the
holes.
REVERSE A DRYER DOOR
6. Install the hinge screw-hole cover on the
opposite side of the door opening. Align the
two pins, on the back of the cover, with the
two middle holes for the door hinge.
7. Press pins into holes as far as they will go.
8. Separate door halves by removing six
Phillips head screws from the inside door
panel.
9. Lift the inside off the outside door half.
10. Remove the two hinge screw-hole covers
by gently prying two plastic pins out of the
holes for each cover.
Door Strike
Phillips Head
Screw
Hinge Screw
Hole Cover
6 Phillips
Head Screws
Hinge Screw
Hole Covers
To Next Page
