4-15
DOOR HANDLE - DRYER
1. To remove door handle after the door
halves are separated (See page 4-14),
remove three Phillips head screws.
2. Use a flat blade screwdriver and press in,
on the plastic tab, on the inside of the door
handle.
3. Remove the handle from the door.
1. Separate door halves (See page 4-14).
2. Remove door handle (See left column on
this page).
3. Rotate inner lens slightly to release the tabs
securing it to the front door half. Lift the
lens out of the door trim.
INNER DOOR LENS - DRYER
3 Phillips
Head Screws
