4-14
11. Remove four Phillips head screws
securing the hinge to the door.
12. Rotate the hinge 180 degrees and install
it on the other side of the door with the
four screws just removed. There are two
placement pins, in the hinge, that fit into two
holes for correct hinge placement.
13. Install the hinge screw-hole covers where
the hinge was removed from. Align the two
pins on the back of the cover with the two
holes for the door hinge screws. Press the
pins into the holes as far as they will go.
14. Rotate the outer door 180 degrees. Place
the inner door into the outer door with the
hinge on the opposite side of the handle.
15. Place inner door into outer door with hinge
opposite the handle side.
16. Reinstall the six Phillips head screws in
the door. The longest screw goes in the
hole at the top of the door. These screws
have high and low threads for holding in
plastic.
NOTE: Washer doors are not reversible.
Handle
Hinge
4 Phillips
Head Screws
Hinge Hole
Covers
