4-1
5. To remove the detergent flapper, place a
flat blade screwdriver in the slot between
the hinges at the top of the flapper and twist
both ways to release the flapper.
6. The locking tab can be removed by
unclipping it from slots in the top left back
corner of the chemical dispenser drawer.
7. Reinstall it by clipping it onto the crossbar in
the openings.
COMPONENT ACCESS
1. Pull the chemical dispenser drawer out as
far as it will go.
2. Press the release tab down in the top left
back corner of the drawer using a putty
knife or a small flat blade screwdriver.
3. Pull the dispenser drawer out of the washer.
4. The detergent cup insert can be removed
for cleaning by lifting it out of the chemical
dispenser drawer.
CHEMICAL DISPENSER DRAWER AND PARTS
Release Tab
Detergent
Cup Insert
Detergent
Flapper
Locking Tab
To Next Page
