4-2
12. There is a bottom cover under the bleach
and fabric dispenser cups. This cover
should be removed and the siphon holes
cleaned to maintain good elimination of
chemicals during the cycle.
8. To remove the front decorative plate of
the chemical dispenser remove four T-20
security screws.
9. The chemical dispenser drawer facia is
secured with sheet metal screws. The User
Interface facia is secured with machine
screws. Make sure not to interchange these
screws.
10. The front of the chemical dispenser
drawer is called the handle, and it can come
off if pulled too hard.
11. Reinstall the handle by straightening
the tabs, hook the top three tabs onto the
drawer and rotate the front down to engage
the three tabs at the bottom into the slots of
the drawer.
