Maytag MLE22PD - Door Switch - Dryer; Blower Housing Cover

4-21
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Remove the dryer front panel
(See page 4-20).
2. Lift the locking tab and disconnect the door
switch wire connector.
3. Squeeze two tabs on the end of the door
switch and push them through the hole from
the back side of the dryer front panel.
4. Rotate the other end of switch assembly up
and push it through the hole in front panel.
5. Pull the switch and wire connector out from
the front of the panel.
DOOR SWITCH - DRYER
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Remove the control panel bracket
(See page 4-8).
2. Remove the dryer front panel
(See page 4-20).
3. Remove four 1/4” hex head screws
securing the blower housing cover to the
blower housing.
4. Support the cover when removing the last
screw.
5. Pull the cover out and down to remove the
blower housing cover.
BLOWER HOUSING COVER
Two 1/4” Hex
Head Screws
Two 1/4” Hex
Head Screws
Door Switch
Connector
Two Tabs
